FIRMWARE 1.0.3.4 GXW4248 USER MANUAL PAGE 44 OF 54
Handset volume adjustment. RX is for receiving volume (direction FXSto analog phone), TX
is for transmission volume (Analog phone to FXS). Default values are 0dB
parameters. Loudest volume: +6dB Lowest volume: -6dB.
Canceller (LEC)
Default is No. If set to “Yes”, device will not use LEC to remove echo from a voice
communication.
Depends on standard phone type (and location)
Select the value according to the local Telco standard where the GXW4248 is installed.
Please refer to the pull down list to select.
Default is No. Use only if proxy supports 484 response. This parameter controls whether the
phone will send an early INVITE each time a key is pressed when a user dials a number. If set
to “Yes”, an INVITE is sent using the dial-number collect
ed thus far; Otherwise, no INVITE is
sent until the “(Re-
)Dial” button is pressed or after about 5 seconds have elapsed if the user
forgets to press the “Re-
Dial” button. The “Yes” option should be used ONLY if there is a SIP
proxy configured and the pro
xy server supports 484 Incomplete Address response. Otherwise,
the call will likely be rejected by the proxy (with a 404 Not Found error).
This feature is NOT designed to work with and should NOT be enabled for direct IP-to-
calling.
Sets the prefix added to each dialed number.
