Interface Type
Select the network interface to monitor.
WAN
LAN
Both
The default is “WAN”.
Enable SFTP Data Sync
Check this box to save the capture files in the SFTP server. Please make sure the configuration of data synchronizatio
works in advance.
Storage to External
Device
Check this box to activate storage of the capture either on the USB or SD Card.
Capture Filter Enter the filter to obtain the specific types of traffic, such as (host, src, dst, net, proto…).
Start Click to start the trace.
Stop Click to stop the trace.
Download Click to download the trace if the trace is stored locally.
Table 51: Ethernet Capture Parameters
The output result is in .pcap format. Therefore, users could specify the capture filter as used in the general network traffic capture tool (host, src, d
protocol, port, port range) before starting to capture the trace.
IP Ping
Enter the Target Host using either a hostname or an IP address. Then press the “Start” button. The output result will dynamically be displayed in th
window below.
Figure 87: IP Ping
Traceroute
