1. Hardware Checklist
2020/2040 Logger x 1
CD containing software x 1 (SQA100)
2020/2040 SERIES Quick Start manual (this booklet) x 1
USB Cable x 1 (LC77)
Mounting bracket/stand for logger x 1 (WB6)
Batteries, 6 x AA
Current shunt resistors, 10R x 4 (CS202)
Connectors: 6 way x 4 (18097), 4 way x 1 (13975), 3 way x 1
(14174), with cable ties
ote: 2040 Logger is supplied with an extra 4 x 6 way
connectors as above (18097).
Version 2 - July 2004
Page 2
18108
