Grant GSD1 User Manual

5.1 Installation Summary
The standard installation kit allows solar
collectors to be fitted vertically onto
horizontal mounting rails.
Item Description
01 Collector
02 Mounting rail set
03 Roof Anchors -C to flat roof
anchors
04 Rail profile
05 Anchor block
06 Collector connection kit
07 Collector to collector
connection kit
08 Cylinder anchor bolt
09 Fixing Bracket
11 Hydraulic connection
12 Insulation
13 Temperature sensor
14 Mounting hooks
15 Cruciform
07-A
12
06
13
11
01
04
03-C
08
09
05
04
14
02
Figure 39: Installation Summary,
Vertical Solar Collector Layout
Flat Roof System
Installation
19
