Grant GSD1 User Manual

7
2 Package Contents
Package Contents
2.1 Standard Installation Kits
For ‘On-roof and ‘Flat roof’ Installations (in portrait format)
Table 1: Installation Kit Contents
Standard 1 Standard 2 Standard 3 Standard 4 Standard 5
Article Collector Kit Collector Kit Collector Kit Collector Kit Collector Kit
Mounting rail extension kit only 2 2 (plus extension kit) 4 4 (plus extension kit)
Mounting hook 246810
Cylinder bolt 4 8 12 16 20
Fixing bracket 4 8 12 16 20
Anchor block 4 8 12 16 20
Collector flow/return pipe c/w insulation 22222
Collector to collector connector c/w insulation 01234
Installation and operating instructions 11111
On-Roof installation
Roof anchor* 4 6 8 10 12
Flat Roof installation
Flat roof angle frame 23345
Securing cruciform kit 11111
* Roof anchor - to suit type of roof covering (see pages 14 to 17) - Slate - Flat tile - Profile tile
For ‘In-roof’ Installations (in portrait format)
Table 2: Installation Kit Contents
Standard 1 Standard 2 Standard 3 Standard 4 Standard 5
Article Collector Kit Collector Kit Collector Kit Collector Kit Collector Kit
Mounting bracket 4 8 12 16 20
Anchor block 4 8 12 16 20
Collector flow/return pipe c/w insulation 22222
Collector to collector connector c/w insulation 01234
Cylinder bolt 4 8 12 16 20
Side gutter LH 11111
Side gutter RH 11111
Base tray – lower section** 12345
Base tray – upper section** 12345
Cover strip 23456
Bottom apron flashing 1-piece*** 10000
Bottom apron flashing LH*** 01111
Bottom apron flashing RH*** 01111
Bottom apron flashing Intermediate*** 00123
Bottom flashing 1-piece**** 10000
Bottom flashing LH**** 01111
Bottom flashing RH**** 01111
Bottom flashing Intermediate**** 00123
Top cover flashing 1-piece 10000
Top cover flashing LH 01111
Top cover flashing RH 01111
Top cover flashing Intermediate 00123
Closure strip 01234
Fixing screw 1428446076
Clip c/w nail 12 12 12 12 12
Foam draught seal wedge 66666
Foam draught seal block 23456
Mastic bead (roll) 11111
Torx screwdriver bit (T25) 11111
Installation and operating instructions 11111
** Maybe supplied as one tray *** Bottom apron flashing used for tiles only **** Bottom flashing used for slates only
Table 3: Timber Battens (to be supplied by the installer) – minimum lengths (mm)
Bottom batten (30 x 50) 1460 2645 3835 5025 6215
Lower middle batten (30 x 90) 1460 2645 3835 5025 6215
Upper middle batten (30 x 90) 1460 2645 3835 5025 6215
Top batten (30 x 50) 1460 2645 3835 5025 6215
