Differential Controller
User Guide
Setting Own
No. Designation Setting Range Ex Works Settings
User Set Values
01 Set time 0.00 - 24.00 10.00
02 Set weekday 1 - 7 1 (Monday)
03 Day's production Display only/Clear 0
04 Total production Display only/Clear 0
05 Pump kick function switch-on time 00.00 - 24.00 07.00
06 Pump kick function switch-off time 00.00 - 24.00 22.00
Fitter Set Values
20 Enter code No. 0000-9999
21 Code No. 0000-9999 0000
22 Select system 1 - 7 1
Switching Thresholds / Hystereses
30 Switching threshold for difference 1 1K – 30K 3
31 Hysteresis to switching threshold for 1 1K – 10K 3
Special Functions
40 Enable temperature, collector(s) (-20)°C – (+90)°C 35°C
41 Maximum collector temperature 80°C – 180°C 110°C
50 Maximum storage tank temperature 10°C – 130°C 60°C
Pump Kick Function
(Temperature Test Function)
60 Kick duration 0.2s – 59s 0 = OFF
61 Kick pause 10 min – 60 min 30 min
62 Measuring time for 0.5K increase 1 min – 5 min 1 min
Production Estimate
75 Volume flow fix for collector 1 [litre/min] 0-100 0.0 = OFF
78 Mixing ratio 0 – 70 vol. % 40 %
79 Glycol type 0 – 1 0
12 Differential Controller
User Guide
Table 9: Set Values List
