Grant Squirrel SQ2010 SERIES User Manual

28507 Version 6 SQ2010
Page 3
2. General Information
The 2010 uses two C size alkaline batteries located under the removable cover on the rear
of the unit as shown below. To insert new or change the existing batteries:
1. Open the battery cover by releasing the clip (highlighted)
2. Insert 2 C* batteries, ensuring the correct polarity
3. Refit the battery cover
* It is recommended that all replacement batteries are of the same manufacturer, type
and condition.
Battery indicator
When logging please ensure that the batteries in the unit have sufficient capacity to
complete the logging task. This can be checked via the battery indicator located in the
top right of the display.
HIGH LOW
CAPACITY CAPACITY
External power indicator
The logger may be powered from an external source (8-28V DC or USB)
Important: To ensure data protection in the case of an unexpected
power loss, please ensure that batteries are fitted whilst the unit is
operational.
2.1 Installing the batteries
2.2 Power indicator
-
+
Important: Remove the batteries when the logger is not used for
long periods of time or is being transported
