46
Technical data – RF Set, Transmitter
Power supply: 2 x 1.5 V AA LR6 alkaline batteries
Batteryservicelife: 2years(dependingonswitchingfrequency)
Roomtemperaturedisplayresolution:0.1ºC 
Temperaturesettingdisplay: Program: +5ºC…+32ºC(0.5ºCsteps) 
 Frostprotection: 5ºC(adjustable3ºC…7ºC)
Time setting resolution: Time of day: 1 minute
Program: 30 minutes
Temperature measurement
(heatingsystem): 3K/hour 
Programming: weekly program with up to 48 time and temperature programs
changes
Pre-programmedprograms: 4+1user-dened 
RF signal: 868.3 MHz
RFsignalrange: Indoor30m(2walls+1ceiling)
Protection class/type: II/IP40
Operatingtemperaturerange: Max.45ºC 
Operating humidity range: 10% to 90% RH non-condensing
DimensionsHxWxD(mm): 87x154x27
