101
Contrast ratio (typical) 500:1
Background intensity
(typical)
300 Cd/m
2
Waveform display
range
14 × 8 grids
Afterglow Off, 1 second, 2 seconds, 5 seconds, infinite
Menu display 2 seconds, 5 seconds, 10 seconds, 20 seconds, infinite
Screen saver
Off, 1min, 2min, 5min, 10min, 15min, 20min, 1h, 2h, 5h
Interpolation mode Sine interpolation, linear interpolation
Screen color mode Normal, inverse phase
Display language Simplified Chinese, English
Power supply
Power voltage 100-240 VAC, CAT II, auto selection
AC power supply
frequency range
45Hz to 440Hz
Consumed power 50VA Max
Environment
Temperature
Operating: 10 ºC to +40 ºC
Non operating: -20 ºC to +60 ºC
Cooling Forced cooling of fan
Humidity ≤ 90% below 40 ºC
Height
Operating: smaller than 3000m
Non operating: smaller than 15000m
Mechanical specifications
Size 339mm×149mm×111mm (width x height x depth)
Weight About 2.3kg
