ex1) INTERNAL POWER LIMITE = 360W
Using DC POWER 15V / 20A (300W)
If power rate is set to 50%, CH1=150W, CH2=150W can
be used in accordance with internal wattage limitation.
ex2) INTERNAL POWER LIMITE = 360W
AC INTERNAL POWER (120W)
If power rate is set to 50%, CH1=60W, CH2=60W can be
used in accordance with AC power wattage limitation.
One output takes max 250Wattage.
ex1) INTERNAL POWER LIMITE = 360W
ONE OUTPUT MAX WATTAGE = 250W
DC POWER 15V / 30A (450W)
If power rate is set to 90% in output 1, 450W X 90%=
405W can be used, but it could have max 250W due to
the wattage limitation.
b. OPERATING GRAPHIC
- It should be activated like data view menu above pos.7.
c. BALANCER GRAPHIC
- It should be activated like balance menu above pos.6.
13-2. CYCLE OPERATION SCREEN
- It shows an order of cycle operation.
13-3. STEP-CHARGE OPERATION SCREEN
- It shows an order of STEP-CHARGE
- If “DISCHARGE OFF” is set, wait for reserve time then starts charging.
- If “DISCHARGE ON” is set, discharges first then wait for reserve time.
- If “DISCHARGE ON” is set, wait for one minute then starts charging.
- Shows step number being used and status of IMPULSE and REFLEX
13-4. REPEAK CHARGE OPERATION SCREEN
- It shows an order of REPEAK CHARGE
13-5. TYRE HEATER OPERATION SCREEN
- This should be activated like the setup screen, and “==OPERATING==” should be
shown at the top line of the screen.
- All parameters can be changed during operating.
13-6. MOTOR OPERATION SCREEN
- This should be activated like the setup screen, and “==OPERATING==” should be
shown at the top line of the screen.
- All parameters can be changed during operating.
