Specification:
Pico8 Pico25 POWER MOS 60
Operating voltage: 6-11,1V 6-12V 7,2-36V
Functions:
forward/stop/brake forward/stop/brake forward/stop/brake
Pulse frequency: 1000Hz 1000Hz 1000Hz
R DSon in Ohm approx.: 0,004 0,001 0,0009
Start-up current: 16A 80A 120A
Continuous current: 8A 25A / 1min. 40A 60A
BEC: 5V/1A 5V/3A
NO BEC, Opto-coupler
BEC current peak approx.: 2A 4A -
Max. dissipated power, BEC:
1W 2,5W -
For No. Of servos: 1-3 2-5 -
Temperature cut-off: - yes yes
Brake: yes, programmable yes, programmable yes, programmable
Dimensions in mm approx:20 x 11 x 6 25 x 18 x 7 46 x 30 x 9
Weight approx.: 7g 19g 40g
GRAUPNER GmbH & Co. KG, D-73230 KIRCHHEIM/TECK GERMANY
Liability for printing errors excluded. We reserve the right to introduce modifications. 09/04
Environ mental Protection Notes
When this product comes to the end of its useful life, you must not dispose of it in
the ordinary domestic waste. The correct method of disposal is to take it to your
local collection point for recycling electrical and electronic equipment. The symbol
shown here, which may be found on the product itself, in the operating
instructions or on the packaging, indicates that this is the case.
Individual markings indicate which materials can be recycled and re-used. You
can make an important contribution to the protection of our common environment
by re-using the product, recycling the basic materials or recycling redundant
equipment in other ways.
Remove batteries from your device and dispose of them at your local collection point for
batteries.
If you don’t know the location of your nearest disposal centre, please enquire at your local council
office.
