Gravely pro-stance 36 994131 User Manual

EN - 11
1. Right Transaxle Bypass Lever
2. Left Transaxle Bypass Lever
3. Operator Platform
4. Steering Levers
5. Battery
6. Fuel Tank
7. Fuel Cap
8. Fuel Gauge
9. Discharge Chute
10. Ignition Switch
11. Choke Control Knob
12.
Throttle Lever
13. Oil Pressure Light
14. Hour Meter
15. Mower Deck Lift Pedal
16. Mower Deck Lift Lever
17. Transport Lock Knob
18. Height-of-Cut (HOC) Index Wheel
19. Parking Brake Lever
20. Power Take Off (PTO) Switch
21. Pad/Rear Access Panel
22. Belt Access Panel
23. Hydraulic Oil Reservoirs
24. Carbon Canister (Model 994139)
CONTROLS AND FEATURES
17
19
12
13
18
Figure 4
10
11
14
20
21
3
6
7
15
1
2
16
8
9
4
5
22
23
3
24

Gravely pro-stance 36 994131 Specifications

General

Model	Pro-Stance 36 994131
Engine Displacement	603 cc
Cutting Width	36 inches
Deck Type	Fabricated
Wheel Size (front)	13 x 6.5-6
Wheel Size (rear)	20 x 10-8
Turning Radius	Zero-turn
Height Adjustment	1.5 to 5 inches
