Gravely Pro-Turn ZX 48 User Manual

Gravely Pro-Turn ZX 48

46 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

Pro-Turn ZX

05265600 • 10/18

Printed in USA

E10

ENGLISH

FRANÇAIS

Models

991230 – Pro-Turn ZX 48

(SN 000101 +)

991232 – Pro-Turn ZX 52

(SN 000101 +)

991234 – Pro-Turn ZX 60

(SN 000101 +)

Operator’s Manual

Manuel de I’utilisateur

Table of Contents

Questions and Answers:

A
Adam TannerAug 14, 2025
How to troubleshoot starting issues in my Gravely Lawn Mower?
- V
  vpowellAug 14, 2025
  If your Gravely Lawn Mower engine won't start, several factors could be at play. First, the safety interlock system might not be engaged or could be faulty, so you should check it. The fuel tank may be empty, requiring you to fill it. Contaminated fuel can also prevent starting, so replace it with clean fuel. A discharged battery is another common cause, so ensure it is charged. Also, check the connection between the battery and cables, tightening or cleaning them as necessary. Finally, loose spark plug wires or faulty plugs can be the culprit; connect the wires or replace the spark plugs.
S
sierraharveyAug 17, 2025
Why is the cutting quality poor on my Gravely Lawn Mower?
- S
  sharonjohnsonAug 17, 2025
  If your Gravely Lawn Mower isn't cutting well, several factors could be responsible. The mower blades might not be level, or the deck pitch could be incorrect; level and adjust them. Dull or faulty blades will also cause poor cutting, so sharpen or replace them. If you're mowing too fast, try driving slower. Poor belt tension or condition can also affect cutting quality, so replace the mower belts. Avoid setting the cutting height too low, and for very tall grass, consider mowing twice.
J
Jamie McdanielAug 20, 2025
Why does my Gravely Pro-Turn ZX 48 Lawn Mower engine run rough?
- L
  llucasAug 20, 2025
  A rough-running engine in your Gravely Lawn Mower can stem from a few causes. Check if the choke control knob is in the 'on' position and move it to 'off'. Also, a plugged air filter cartridge can cause this issue, so clean or replace it.
D
Dawn HallAug 23, 2025
What causes PTO malfunctions in my Gravely Lawn Mower?
- M
  Michelle WhiteAug 25, 2025
  PTO malfunctions on your Gravely Lawn Mower can occur if the operator presence switch is not engaged; activate it by sitting on the operator seat. Also, the PTO belt could be faulty and need replacement.
D
Daniel BaxterAug 27, 2025
What to do if my Gravely Pro-Turn ZX 48 Lawn Mower does not drive?
- D
  Donna FloresAug 27, 2025
  If your Gravely Lawn Mower isn't driving, check if the transaxles are bypassed and engage the levers.
L
Laura GutierrezAug 30, 2025
What to do if my Gravely Lawn Mower engine overheats?
- S
  Stacy RobbinsAug 30, 2025
  If your Gravely Lawn Mower engine is overheating, it could be due to low engine oil level, so add more oil. Another cause might be plugged cooling fins, which require cleaning.
R
Randy JonesSep 3, 2025
Why does my Gravely Pro-Turn ZX 48 Lawn Mower not drive straight?
- J
  Jasmin ObrienSep 3, 2025
  If your Gravely Lawn Mower isn't driving straight, incorrect tire pressure could be the cause; check and correct it. Also, the steering levers may need adjustment.
H
Heather JacksonSep 6, 2025
Why does my Gravely Lawn Mower move when the engine is off and the parking brake is engaged?
- A
  Amanda OlsonSep 6, 2025
  If your Gravely Lawn Mower moves with the engine off and the parking brake engaged, the parking brake likely needs adjustment.
M
Mary RomanSep 9, 2025
What to do if blades of Gravely Pro-Turn ZX 48 do not stop within 5 seconds?
- K
  Kimberly GardnerSep 9, 2025
  If the blades of your Gravely Lawn Mower do not stop within 5 seconds, the clutch brake plates may be worn. Try reversing the clutch brake plates. If they have already been reversed, replace the clutch.

Gravely Pro-Turn ZX 48 Specifications

General

Engine	Kawasaki FR691V
Engine Manufacturer	Kawasaki
Engine Model	FR691V
Engine Displacement	726 cc
Engine Power	23 HP
Cutting Width	48 inches
Cutting Height	1.5 - 5 inches
Deck Type	Fabricated
Deck Material	10-gauge steel
Transmission Type	Hydrostatic
Transmission Manufacturer	Hydro-Gear
Reverse Speed	4 mph
Tires (Front)	13 x 6.5-6
Turning Radius	Zero-turn
Engine Type	V-Twin
Transmission	Hydro-Gear
Forward Speed	8.5 mph

Summary

SAFETY

General Safety Rules and Symbols

Covers safety rules, symbols, signal words, and operator training requirements.

Safety Decals

Details safety decals on the unit, their locations, and descriptions for hazard awareness.

OPERATION

Pre-Operation Checks and Starting

Covers pre-operation inspections, emergency stopping, starting procedures, and ROPS positioning.

Operating the Unit and Slopes

Instructions for operating, maneuvering, and safely handling slopes, including manual movement.

CONTROLS AND FEATURES

Control Panel Overview

Description of ignition, choke, throttle, PTO, hour meter, and height-of-cut adjustment.

Operator Controls and Levers

Details on lift pedals, seat adjustment, ROPS, parking brake, steering, and bypass levers.

MAINTENANCE

Maintenance Schedule and Service Parts

Outlines recommended maintenance intervals and lists available service parts.

Component Checks and Service Procedures

Covers checking safety interlocks, oil, tires, fasteners, lubrication, and parking brake.

Blade, Battery, and Hydraulic Maintenance

Procedures for mower blade maintenance, battery service, and hydraulic system checks.

Belt and Transaxle Maintenance

Instructions for replacing mower and transaxle drive belts, and reverse clutch brake plates.

SERVICE & ADJUSTMENTS

Seat and Steering Adjustments

Guides for adjusting the operator's seat and steering lever height and alignment.

Unit Alignment and Transaxle Calibration

Procedures for achieving straight tracking, adjusting limiter bolts, and calibrating transaxles.

Electrical and Deck Adjustments

Covers electrical service (fuses/relays) and mower deck removal, leveling, and pitching.

TROUBLESHOOTING

Engine and Drive System Issues

Diagnosing and resolving problems with engine starting, running, and unit drive.

Performance and Quality Troubleshooting

Addresses issues with PTO, brakes, steering, cutting quality, and blade stopping.

STORAGE

Storage and Preparation Guidelines

Covers short-term, long-term storage, and start-of-season preparation procedures.

ACCESSORIES

Accessory Catalog and Part Numbers

Lists available accessories, bagger kits, and their respective part numbers.

SPECIFICATIONS

Model Technical Specifications

Provides detailed technical data and dimensions for Pro-Turn ZX models.

WARRANTY

Warranty Terms and Exclusions

Details warranty coverage, extensions, limitations, and items not covered.
