Gravely Promaster 200 - Hydraulic Cylinder Installation

8 - 31
3. Reconnect hydraulic cylinder to mower lift
weldment, noting where it was previously
connected.
4. Connect hydraulic hoses.
5. Service electric/hydraulic pump reservoir.
PF0881
OF0100
Figure 18
1. Motor Assembly
2. Adapter Assembly
3. Tank Reservoir
4. Hydraulic Lift Cylinder
1
2
3
4
1
2
3
4
60" Mower
50" Mower
