Gravely Promaster 200 - Seat Switch, Hourmeter, Lift Switch Test Values (Models 991005, 006)

13 - 57
Promaster 100 Kohler Command - 50" Deck with Lift, Models 991005, 006
Normally open contacts. Manually activated.
Contact resistance is 0.1-0.3 ohms when correct.
Key switch must be in RUN position to provide power to deck lift pump.
Seat Switch Off Run Start
Pink 12.00 Vdc 12.00 Vdc
Black (to ground) To Ground
Hourmeter Off Run Start
Black To Ground
White 12.00 Vdc 12.00 Vdc
Lift Switch - Deck Off Run Start
Red 12.00 Vdc 12.00 Vdc
Green 12 volt when activated
Blue 12 volt when activated
