Promaster 100 Kohler Command - 50" Deck with Lift, Models 991005, 006
Pins 85-86 coil resistance is 87-100 ohms.
Pins 30-87A normally closed.
Contact resistance is 0.1-0.3 ohms when correct.
Normally open contacts. Manually activated.
Contact resistance is 0.1-0.3 ohms when correct.
Normally open contacts. Manually activated.
Contact resistance is 0.1-0.3 ohms when correct.
Normally open contacts. Manually activated.
Contact resistance is 0.1-0.3 ohms when correct.
Relay - Deck Lift Off Run Start
Black (85) To Ground
Purple 12.00 Vdc 12.00 Vdc
Red 12.00 Vdc 12.00 Vdc
Red 12.00 Vdc 12.00 Vdc 12.00 Vdc
Open 12.00 Vdc
PTO Switch Off Run Start
Yellow/Red 12.00 Vdc 12.00 Vdc
Brown/Yellow 12.00 Vdc 12.00 Vdc
Purple 12.00 Vdc 12.00 Vdc
Purple/White (to clutch) 12 volt when activated
Right Neutral Switch Off Run Start
Red/Yellow 12.00 Vdc 12.00 Vdc
Red/Violet 12.00 Vdc 12.00 Vdc
Left Neutral Switch Off Run Start
Brown/Yellow 12.00 Vdc 12.00 Vdc
Red/Yellow 12.00 Vdc 12.00 Vdc
To Next Page
