Promaster 100 Kohler Command - 50" Deck with Lift, Models 991005, 006
Contact resistance is 0.1-0.3 ohms when correct.
Pins 85-86 coil resistance is 87-100 ohms.
Pins 30-87A normally closed.
Contact resistance is 0.1-0.3 ohms when correct.
Pins 85-86 coil resistance is 87-100 ohms.
Pins 30-87A normally closed.
Contact resistance is 0.1-0.3 ohms when correct.
Ignition Switch Off Run Start
Red (B) 12.00 Vdc 12.00 Vdc 12.00 Vdc
Purple (A) 12.00 Vdc 12.00 Vdc
Red/Violet (S2) 12.00 Vdc 12.00 Vdc
Brown (S1) 12.00 Vdc 12.00 Vdc
Relay - Seat Off Run Start
Pink (85) 12.00 Vdc 12.00 Vdc
Purple (86) 12.00 Vdc 12.00 Vdc
Yellow/Red (87) 12.00 Vdc 12.00 Vdc
Purple (30) 12.00 Vdc 12.00 Vdc
Open (87A)
Relay - Start/Kill Off Run Start
Black (85) To Ground
Yellow/Red (86) 12.00 Vdc 12.00 Vdc
Open (87)
Black (30) To Ground
White/Black (87A) From Engine Magneto
To Next Page
