13 - 60
Promaster 100 Kohler 16 -18 HP
Contact resistance is 0.1-0.3 ohms when correct.
Normally open switches, manually activated.
Contact resistance is 0.1-0.3 ohms when correct.
Normally open switches, manually activated.
Contact resistance is 0.1-0.3 ohms when correct.
Pins 85-86 coil. Resistance is 87-100 ohms.
Contact resistance is 0.1-0.3 ohms when correct.
Pins 30-87A normally closed, manually activated.
Ignition Switch Off Run Start
Red (I) 12.00 Vdc 12.00 Vdc 12.00 Vdc
Light Blue (A) 12.00 Vdc 12.00 Vdc
Dark Blue (R) 12.00 Vdc 12.00 Vdc
Purple (B) 12.00 Vdc 12.00 Vdc
Brown (S) 12.00 Vdc
Hourmeter Off Run Start
Black 12.00 Vdc 12.00 Vdc
White To Ground
Right Interlock Switch Off Run Start
Brown 12.00 Vdc 12.00 Vdc
Brown/White 12.00 Vdc 12.00 Vdc
Left Interlock Switch Off Run Start
Brown 12.00 Vdc 12.00 Vdc
Brown/White 12.00 to ground 12.00 to ground
Relay Off Run Start
Red and Green (86) 12.00 Vdc 12.00 Vdc
Black (87A) Connected to ground circuit to engine kill
Green (30) Connected to ground
Green (85) Connected to ground through time delay
