Promaster 100 - Briggs & Stratton
Normally open, manually activated.
Contact resistance is 0.1-0.3 ohms when correct.
Normally open switches, manually activated.
Contact resistance is 0.1-0.3 ohms when correct.
Normally open switches, manually activated.
Contact resistance is 0.1-0.3 ohms when correct.
Ignition Switch Off Run Start
Brown (S) 12.00 Vdc
Red (B) 12.00 Vdc 12.00 Vdc 12.00 Vdc
White (M) Connected to ground
Yellow (L) 12.00 Vdc 12.00 Vdc
White/Red (G) Engine Magneto
Oil PSI Light Off Run Start
Orange 12.00 Vdc 12.00 Vdc
Green 12.00 Vdc 12.00 Vdc
Hourmeter Off Run Start
Black 12.00 Vdc 12.00 Vdc
White 12.00 to ground 12.00 to ground
PTO Interlock Switch Off Run Start
Brown 12.00 Vdc 12.00 Vdc
Brown/White 12.00 Vdc 12.00 Vdc
Right Interlock Switch Off Run Start
Brown/White 12.00 Vdc 12.00 Vdc
Brown 12.00 Vdc 12.00 Vdc
