13 - 65
Promaster 100 - Briggs & Stratton
Normally open switches, manually activated.
Contact resistance is 0.1-0.3 ohms when correct.
Pins 85-86 coil. Resistance is 87-100 ohms.
Contact resistance is 0.1-0.3 ohms when correct.
Pins 30-87A normally closed.
Normally open contacts. Large terminal contact resistance is 3 to 5 ohms.
Small terminal contact resistance is 0.1 to 0.3 ohms.
Left Interlock Switch Off Run Start
Brown 12.00 Vdc 12.00 Vdc
Brown/White 12.00 Vdc 12.00 to ground
Relay Off Run Start
Red and Green (86) 12.00 Vdc 12.00 Vdc
Black (87A) Connected to ground kill thru relay pin 30
Green (85) 12.00 Vdc 12.00 to ground
Green (30) Connected to ground
Time Delay Module Off Run Start
Brown 12.00 Vdc 12.00 Vdc
Yellow 12.00 Vdc 12.00 Vdc
Green 12.00 Vdc 12.00 Vdc
Solenoid Off Run Start
Red (battery input) 12.00 Vdc 12.00 Vdc
Red (starter lead) Connected to ground kill thru relay pin 30
Brown (from key switch) 12.00 Vdc 12.00 to ground
Brown (to module and switches Connected to ground circuit
