13 - 70
Model 992010, 011 Kawasaki 18 HP, Briggs & Stratton
Contact resistance is 0.1-0.3 ohms when correct.
Pins 85-86 coil resistance is 87-100 ohms.
Pins 87 and 30 normally open.
Contact resistance is 0.1-0.3 ohms when correct.
Pins 85-86 coil resistance is 87-100 ohms.
Pins 87A and 30 normally closed.
Contact resistance is 0.1-0.3 ohms when correct.
Ignition Switch Off Run Start
Brown (S) 12.00 Vdc
Black (I) 12.00 Vdc 12.00 Vdc 12.00 Vdc
Purple (B) 12.00 Vdc 12.00 Vdc
Blue (R) 12.00 Vdc 12.00 Vdc
Green (A) 12.00 Vdc 12.00 Vdc
Start Relay Off Run Start
Brown (86) 12.00 Vdc
Red (30) 12.00 Vdc 12.00 Vdc 12.00 Vdc
Yellow (87) 12.00 Vdc
Orange-Brown/White (85) Connected to ground
Time Delay Module Off Run Start
Purple (86) 12.00 Vdc 12.00 Vdc
Red/White (87A) Connected to ground, for kill circuit
Pin (85) (connected to ground thru module) 12.00 Vdc 12.00 Vdc
Green (30) Connected to ground
