13 - 71
Model 992010, 011 Kawasaki 18 HP, Briggs & Stratton
Normally open switches.
Contact resistance is 0.1-0.3 ohms when correct.
Normally open switches.
Contact resistance is 0.1-0.3 ohms when correct.
Three pole, two way momentary switch.
Normally open switches.
Contact resistance is 0.1-0.3 ohms when correct.
Right Neutral Switch Off Run Start
Brown Connected to ground
Brown Connected to ground
Ignition Switch Off Run Start
Brown (S) 12.00 Vdc
Black (I) 12.00 Vdc 12.00 Vdc 12.00 Vdc
Purple (B) 12.00 Vdc 12.00 Vdc
Blue (R) 12.00 Vdc 12.00 Vdc
Green (A) 12.00 Vdc 12.00 Vdc
Left Neutral Switch Off Run Start
Brown Connected to ground
Black Connected to ground
Pump Lift Switch Off Run Start
Black 12.00 Vdc 12.00 Vdc 12.00 Vdc
White Connected to ground
Hourmeter Off Run Start
Green 12.00 Vdc 12.00 Vdc
Oil Light Off Run Start
Green 12.00 Vdc 12.00 Vdc
Yellow Connected to ground thru PSI sensor
