13 - 78
Models 992013, 014, 015, 016, 301
Normally open switches.
Contact resistance is 0.1-0.3 ohms when correct.
Normally open switches.
Contact resistance is 0.1-0.3 ohms when correct.
Three pole, two way momentary switch.
Normally open switches.
Contact resistance is 0.1-0.3 ohms when correct.
Right Neutral Switch Off Run Start
Brown Connected to ground
Brown Connected to ground
Left Neutral Switch Off Run Start
Brown Connected to ground
Black Connected to ground
Pump Lift Switch Off Run Start
Black 12.00 Vdc 12.00 Vdc 12.00 Vdc
White Connected to ground
Hourmeter Off Run Start
Green 12.00 Vdc 12.00 Vdc
PTO Switch Off Run Start
Orange 12.00 Vdc 12.00 Vdc
Light Blue When selected to on position - 12.00
White (clutch) Connected to ground
Oil Light Off Run Start
Green 12.00 Vdc 12.00 Vdc
Yellow Connected to ground thru PSI sensor
