Gravely Promaster 200 - Seat Switch and Time Delay Test Values (Models 992013-301)

13 - 79
Models 992013, 014, 015, 016, 301
Normally open switches, manually activated.
Contact resistance is 0.1-0.3 ohms when correct.
Module cannot be tested.
Seat Switch Off Run Start
Yellow 12.00 Vdc 12.00 Vdc
Green Holding circuit for the time delay
Time Delay Off Run Start
Orange 12.00 Vdc
Green 12.00 Vdc 12.00 Vdc
