To Next PageTo Next PageWhat to do if my Gravely ZT HD won't drive?
If your Gravely Lawn Mower does not drive, make sure that the transaxles are engaged by their levers. If the levers are engaged, but the unit still doesn't drive, the transaxle drive belt may be faulty, or the transaxles themselves may be faulty, in which case you should contact your Gravely dealer.
How to fix a Gravely ZT HD Lawn Mower that does not drive straight?
If your Gravely Lawn Mower does not drive straight, it could be due to incorrect tire pressure, so check the tire pressure. Also, the steering levers may need adjustment.
How to troubleshoot a Gravely ZT HD Lawn Mower when the engine does not start?
If your Gravely Lawn Mower engine doesn't start, several factors could be the cause. First, make sure the Safety Interlock System is properly engaged and not faulty. If the fuel tank is empty, refill it. Contaminated fuel can also prevent starting, so replace it with clean fuel. A discharged battery will also prevent the engine from starting, so charge the battery. Also, check the connection between the battery and cables, and tighten or clean them if necessary. Loose spark plug wires or faulty spark plugs can also be the problem; connect the wires or replace the spark plugs. If these steps don't resolve the issue, there may be a fault in the electrical system or the engine itself, in which case you should contact your Gravely dealer.
Why is the cutting quality poor on my Gravely Lawn Mower?
If your Gravely Lawn Mower exhibits poor cutting quality, several factors could be responsible. Ensure the mower blades are level and the mower deck pitch is correct. Dull or faulty mower blades can also cause this issue, so sharpen or replace them. If you're mowing too fast, try slowing down. Poor belt tension or condition can also affect cutting quality, so replace the mower belts if needed. Avoid setting the cutting height too low; for very tall grass, consider mowing twice.
What to do if my Gravely Lawn Mower engine runs rough?
If the engine of your Gravely Lawn Mower runs rough, the choke control knob might be in the 'on' position. If so, move the knob to the 'off' position. Additionally, a plugged air filter cartridge could be the cause, so clean or replace it. If neither of these solutions resolves the issue, the engine itself may be faulty, and you should contact your Gravely dealer.
Why does my Gravely Lawn Mower engine overheat?
If your Gravely Lawn Mower is overheating, it might be due to a low engine oil level, so add engine oil. Another potential cause is plugged cooling fins, so clean the engine. If the problem persists, the engine itself may be faulty, and you should contact your Gravely dealer.
Why is the PTO malfunctioning on my Gravely ZT HD Lawn Mower?
If the PTO on your Gravely Lawn Mower malfunctions, first ensure the operator presence switch is activated by sitting on the operator seat. If the switch is engaged and the PTO still malfunctions, the operator presence switch may be faulty. Also, the PTO belt might be faulty and needs replacement. If these steps don't resolve the issue, the PTO switch, wiring, connectors, or clutch could be faulty, and you should contact your Gravely dealer.
What causes my Gravely ZT HD to move when the engine is off and the parking brake is on?
If your Gravely Lawn Mower moves with the engine off and the parking brake engaged, it may be that the parking brake needs adjustment. If adjusting the lever doesn't solve the problem, the parking brake itself may be faulty, and you should contact your Gravely dealer.
Why does my Gravely ZT HD creep when the steering levers are in neutral?
If your Gravely Lawn Mower creeps when the steering levers are in the neutral position, the transmission and/or linkage may need adjustment, and you should contact your Gravely dealer.
What to do if blades do not stop within 5 seconds on Gravely ZT HD?
If the blades on your Gravely Lawn Mower do not stop within 5 seconds, it indicates that the clutch brake plates are worn. Try reversing the clutch brake plates. If they have already been reversed, replace the clutch.
General| Engine Brand | Kawasaki |
|---|---|
| Transmission Type | Hydro-Gear ZT-3100 |
| Turning Radius | Zero-turn |
| Cutting Width | 60 inches |
| Fuel Capacity | 5 gallons |
| Deck Material | Steel |
| Engine Model | FR691V |
Emphasizes product registration for warranty activation and communication with AriensCo.
Covers essential safety rules, practices, laws, and required operator training for safe operation.
Explains the meaning and use of safety alert symbols and signal words like Danger, Warning, and Caution.
Illustrates the placement of various safety decals on the machine for user awareness.
Explains critical DANGER decals related to discharge hazards, amputation, and general warnings.
Covers hazards related to tipping, service, bystanders, loss of traction, hot parts, and rotating parts.
Details critical warnings for fuel handling, smoking, and safe operation with the Rollover Protection Structure (ROPS).
Covers pre-operation checks, safe operating practices, and precautions for children and slopes.
Addresses fire prevention, fuel handling, and guidelines for safe hauling and towing.
Guidelines for proper use, inspection, and maintenance of the ROPS for operator safety.
Steps for unpacking, removing protective materials, and installing the seat and battery cables.
Final assembly tasks including ROPS positioning, transaxle engagement, and brake release.
Diagrams identifying major controls and features across different model series.
Details the function and operation of the ignition key, throttle control, and choke knob.
Explains the PTO knob, hour meter, and the height-of-cut adjustment system for mowing.
Describes transport lock, deck lift, seat adjustment, safety interlock, steering, and bypass levers.
Covers emergency stopping, fuel/oil checks, safety interlock tests, and ROPS positioning.
Instructions for lowering the ROPS center bar for clearance, with safety warnings.
Detailed steps for starting the engine, including choke and throttle settings.
Guides on releasing the brake, engaging PTO, and using steering levers for mowing.
Procedures for safely stopping the engine and moving the unit manually via bypass levers.
Instructions on how to release the deck from its transport lock position.
A schedule detailing maintenance tasks required at different operating hour intervals.
Lists various replacement parts and their corresponding part numbers for different models.
Guides on positioning the unit for service and verifying the parking brake functionality.
Details on checking engine oil levels and recommended tire pressures for optimal performance.
Instructions for checking fasteners and lubricating pivot points and seat tracks.
Guidance on inspecting mower blades for wear, damage, and safety precautions during handling.
Steps for safely disconnecting, cleaning, and reconnecting battery terminals and cables.
Procedures for checking hydraulic oil levels and changing the hydraulic oil and filter.
Instructions on how to adjust the seat forward, backward, and lock it securely.
Details how to modify the height of the steering levers for optimal operator comfort.
Steps for ensuring proper horizontal alignment and gap between steering levers.
Guidance on adjusting tire pressure to correct unit tracking issues.
Instructions for adjusting limiter bolts to increase or decrease drive wheel speeds.
Addresses issues like engine not starting, running rough, or overheating.
Solutions for unit not driving, PTO issues, and brake engagement problems.
Covers problems with unit tracking, cutting quality, and blades not stopping promptly.
Detailed steps for preparing and storing the unit to prevent damage and deterioration.
Instructions for getting the unit ready for use after a storage period, focusing on fuel and battery.
A list of compatible accessories with their respective part numbers for purchase.
Detailed specifications for ZT HD 48, 52, and 60 models, including dimensions and engine specs.
Technical specifications for ZT HD 44, 48, 52, and 60 models, covering engine, drive, and dimensions.
Specifications for Pro-Turn Z/ZX 48, 52, and 60 models, including engine, drive, and deck details.
Detailed specifications for Pro-Turn ZX 48, 52, and 60 models, covering engine and dimensions.
Details warranty terms and periods for various product groups, including specific model coverage.
Information on special warranty extensions for components like mower deck shell and main frame.
Lists components excluded from warranty and limitations on coverage for wear and tear.
Details items not covered, misuse, fuel requirements, and emissions warranty exceptions.
Covers specific warranty exclusions for job-site vehicles, battery, and engine manufacturer terms.
Outlines customer duties for warranty service, including registration, maintenance, and notification.
Limits AriensCo's liability to repair/replacement and excludes consequential damages.
Addresses Australian Consumer Law rights and other regional legal rights concerning warranties.
