GRE HPGI50 - Page 83

81
No
Spare parts
No
Spare parts
1
Top cover
30
Wire loop with film
2
Top frame
31
Ambient temp. sensor Clip
3
Evaporator
32
Ambient temp. sensor
4
Fan motor bracket
33
Exhaust pipe
5
Left Panel
34
Exhaust temp. sensor
6
Fan motor
35
High pressure switch
7
Casing pipe
36
Pipe (Titanium heat exchanger to Capillary )
8
Fan blade
37
Low pressure switch
9
Front Panel
38
Capillary
10
Ventilation grid
39
Needle Valve
11
Controller
40
Back gas piping
12
Waterproof box
41
Water inlet temp. sensor
13
Controller box
42
Heat exchanger Sensor Clip
14
Evaporator pad
43
Titanium heat exchanger
15
Base tray
44
Joint seal ring
16
Isolation panel
45
Blue rubber ring
17
Compressor heating belt
46
Water connection
18
Compressor
47
Water inlet temp. sensor
19
Evaporator pad
48
Joint seal ring
20
Right Panel
49
Water flow switch
21
Evaporator gas collecting pipe
50
Red rubber ring
22
rubber fixing block
51
Electric box cover
23
Sensor casing pipe
52
Reactor
24
Sensor casing pipe spring leaf
53
Reactor box
25
Coil temp. sensor
54
PCB
26
Distribution pipe
55
Electric box
27
Back panel
56
2-position terminal
28
Pressure gauge
57
3-position terminal
29
Cable connector
58
Clamp
