―６―
(7) Remove the connector from the pedestrian impact sensor.
※ If the battery is reconnected while the pedestrian impact
sensor is disconnected, a popup hood warning light will
appear on your instrument panel.
(8) Remove the bumper/ fascia.
※ Be aware of the bumper fasteners, some adjustment
required to remove the bumper/ fascia.
２
２２
２－
－－
－２
２２
２
Air Intake Duct Removal
Air Intake Duct RemovalAir Intake Duct Removal
Air Intake Duct Removal
(1) Remove the engine oil cooler duct.
※ Allow the oil cooler to hang freely.
(2) Remove the left and right intake duct.
To Next Page
