GReddy Intercooler Kit Installation Manual

―７―
(3) Remove the impact foam.
(4) Remove the front bumper reinforcement.
(5) Disconnect the couplers.
(6) Remove the hood latch cable and cable fastener.
・・・Electrical Couplers
A/C Liquid Tank, Outside Temp. Sensor
Hood Latch, Horn
・・・Cable fastener
・・・Hood :Lock Cable Fastener
(7) Remove the front bumper retainer (upper side).
A/C Liquid Tank
Temp Sensor
Hood Latch
Horn
バンパーブラケット
取り付けボルト×４
※
Air duct mounting bolts are attached to the front bumper
reinforcement, please remove.
アーマチュア
取り付けボルト×８
