―８―
(8) Remove the P/S Oil Cooler mounting bolts, and let the
cooler hang freely.
※ Removal of oil line is not necessary.
※ Be careful not to damage the oil cooler and A/C
condenser.
(9) Disconnect the windshield washer pump and washer liquid
level switch connectors. Remove the front Washer Tube
from the Pump.
Remove the washer liquid level switch fastener。
(10) Remove the washer tank.
(11) Intake Pipe Hose Removal
Intake Pipe Hose Removal Intake Pipe Hose Removal
Intake Pipe Hose Removal
Remove the pressure sensor coupler and the vacuum line
from the top of the recirculation valve. Then remove the
stock charge piping
Tube
Clip
Liquid Switch
To Next Page
