(6) Install the Compression pipe C-3 from the
turbo kit between the pipe I-5 and the
throttle body as shown. Reuse the hoses
and clamps from the turbo kit.
Blow by hose
To air assist
Control valve
3-4 Suction Pipe Installation
(1)Reinstall the Turbo Kit Suction Kit with out
the restrictor.
3-5 Windshield Washer Tank Installation
(1) Install the washer tank brackets A and B as
shown.
(Parts used # 8, 9)
(2) Install the two washer pumps to the
provided washer tank and install the tank on
to the bracket A and B as shown.
Extend the washer tank harness to reach
from the original tank location to the new
location. Refill the tank with washer fluid.
* Make sure not to reverse the positive and
negative wires.
* Make sure not the switch the front pump
and the rear pump connectors.
(Parts used # 7, 10, 11, 21)
To Next Page
