GReddy Turbo Kit User Manual

―４―
34．Oil Pressure Hose ＳＵＳ ４００㎜ １
35． 〃 Union fitting １/８ＰＦ－Ｍ１０ Ｐ１．２５ １
36． 〃 Union fitting １/８ＰＴ－１/８ＰＴ １
37
． 〃 ９０°
Union fitting
１
/
８ＰＴ－１
/
８ＰＦ １
38. 〃 3 Way Fitting １
39． 〃 Copper Washer １０．５φ×１８×１．０ １
40．Oil Return Flange Tube １６φ １
41． 〃 Hose Union １６φ－Ｍ１４ Ｐ１．５ １
42． 〃 Copper Washer １４φ×１９×２．０ １
43．Vacuum Hose ４φ×１２００㎜ (Actuator, Pressure sensor, Air solenoid) １
44．Rubber Hose ７．５φ×３００㎜ (Water Line) １
45． 〃 １２φ×４３０㎜ (Blow-by) １
46． 〃 １５φ×３４０㎜ (Oil return) １
47． 〃 １８φ×４００㎜ (Air-pump) １
48．Silicone Hose 5０φ×７０㎜ 1
49． 〃 ６０φ×７０㎜ 2
50． 〃 ７０φ×７０㎜ １
51． 〃 ５０φ－６０φ Reducer １
52． 〃 ６０φ－７０φ Reducer １
53．Hose Band ８φ Tridon ＃４ ２
54． 〃 １２φ Tridon ＃８ ２
55． 〃 １５φ Tridon ＃１０ ２
56． 〃 １９φ Tridon ＃１２ ３
57． 〃 ５０φ Tridon ＃３２ 3
58
． 〃 ６０φ
Tridon
＃３６
7
59． 〃 ７０φ Tridon ＃４４ ３
60．Gasket Turbo ＩＮ １
61． 〃 Turbo ＯＵＴ １
62
． 〃
Suction Tube Flange
１
63
． 〃
Compression Tube Flange
１
64． 〃 Downpipe （Ring ６５φ） １
65． 〃 Oil return Gasket １
