Gree FM-1.25-9-K

11
Air Curtain
Service Manual
4 Disassembly And Assembly Procedure Of Main Parts
(1) Remove air-in grille. Twist off the screws on air-in grille and then remove the air-in grille.
(2) Remove transformer. Twist off the 2 screws in the g. and then remove the transformer.
(3) Remove the outer case
Twist off the 7 screws on the outer case and 2 screws around the controller and 2 screws at both side as shown in the
g, and then remove the outer case.
(4) Remove controller
1) Twist off the 4 screws and then remove the weak power control board of controller.
