Gree FP-34WM-D Service Manual

9
Floor Ceiling Type Fan
Coil Unit Service Manual
PRODUCT
Model FP-102ZD-K FP-136ZD-K FP-170ZD-K FP-204ZD-K
Code EM56000140 EM56000150 EM56000160 EM56000170
Air ow volume
High
CFM 600 647 1059 1201
m
3
/h 1020 1100 1800 2040
Medium
CFM 450 518 751 927
m
3
/h 765 880 1276 1575
Low
CFM 300 324 500 619
m
3
/h 510 550 850 1051
Capacity
Cooling W 5400 6350 8900 9900
Heating W 11500 13700 19000 21000
Power system
Type
V-Ph-
Hz
220-240V~ 50Hz 220-240V~ 50Hz 220-240V~ 50Hz 220-240V~ 50Hz
Input W 86 78 150 200
Exterior static pressure Pa 0 0 0 0
Water system
Water ow
volume
L/s 0.27 0.32 0.40 0.44
Pressure drop kPa 36 38 52 55
Coil
Type
Aluminum n-
copper tube
Aluminum n-
copper tube
Aluminum n-
copper tube
Aluminum n-
copper tube
Operating
pressure
MPa ≤1.6MPa ≤1.6MPa ≤1.6MPa ≤1.6MPa
Motor
Type
Isolation B Capacitor
startup three-
speed Motor
Isolation B Capacitor
startup three-
speed Motor
Isolation B Capacitor
startup three-
speed Motor
Isolation B Capacitor
startup three-
speed Motor
Capacitor
μ
F 3.0 3.0 5.0 10.0
Sound
pressure level
Sound pressure
level
dB(A) 49 48 50 55
Connection
pipe size
Water inlet
&outlet
inch 3/4(inner groove) 3/4(inner groove) 3/4(inner groove) 3/4(inner groove)
Condensing
water drain
inch
3/4(outer groove) 3/4(outer groove)
3/4(outer groove) 3/4(outer groove)
Outline dimension (W × D × H) mm 1300×188×600 1300×188×600 1590×238×695 1590×238×695
Package dimension (W × D × H) mm 1417×251×739 1417×251×739 1717×333×845 1717×333×845
Net weight kg 31.5 32.5 48.5 48.5
Gross weight kg 36.5 37.5 57 57
Loading quantity
20'GP 108 108 58 58
40'GP 220 220 111 111
40'HQ 244 244 117 117
Wireless remote controller YB1FA(XFAN) YB1FA(XFAN) YB1FA(XFAN) YB1FA(XFAN)
Note:
The water working temperature is from 7ºC (44.6ºF) to 60ºC (140ºF).
The temperature exchange efficiency and enthalpy exchange efficiency are tested under these testing
conditions as below:
(1) Cooling efciency: air 27ºC(80.6ºF) DB, 19ºC(66.2ºF) WB, water temperature in 7ºC(44.6ºF) water out
12ºC(53.6ºF).
(2) Heating efciency: air 20ºC (68ºF) DB, ater temperature in60ºC(140ºF) water out 70ºC(158ºF)
The operating water pressure of the models above is no more than 0.25MPa.
The airow volume is tested when the ESP is 0 Pa.
