Gree FP-34WM-D Service Manual

37
Floor Ceiling Type Fan
Coil Unit Service Manual
No.
Discription
FP-34WM-K FP-51WM-K
QuantityEM51700070 EM51700080
Name of Part Product Code Product Code
1 Left Decoration Plate 261124152 261124152 1
2 Shaft of Louver 10512025 10512025 3
3 Guide Louver Bracket 24212019 24212019 2
4 Guide Louver Fixed Mount 24212018 24212018 1
5 Shaft of Louver 10512026 10512026 2
6 Guide Louver 1051953202 1051953202 1
7 Right Decoration Plate 261124162 261124162 1
8 Left Mounting Plate of Swing Motor 26152005 26152005 1
9 Panel Sub-assy 01532001 01532001 1
10 Mounting Box Sub-Assy 20102041 20102041 1
11 Display Board 30546104 30546104 1
12 Button Panel Sub-Assy 201620042 201620042 1
13 Right Mounting Plate of Swing Motor 26152006 26152006 1
14 Stepping Motor 15212402 15212402 2
15 Press Plate of Swing Motor 26112026 26112026 2
16 Water Tray Component 01279531 01279531 1
17 Pipe Hoop 70812001 70812001 1
18 Drain Pipe Sub-Assy 05235433 05235433 1
19 Handle 26232001 26232001 4
20 Foam Sub-assy of Right Side Plate 12312404 12312404 1
21 Mounting Plate 01332404 01332404 1
22 Decorative Board 26112027 26112027 1
23 Mounting Plate Sub-assy 01847502 01847502 1
24 Electric Box Sub-Assy 01403242 01403242 1
25 Press Wire Holder 24253001 24253001 1
26 Press Wire Board 24253002 24253002 1
27 Terminal Board 42010178 42010178 1
28 Protective Tube 46010013 46010013 1
29 Main Board 30036052 30036052 1
30 Transformer 43110237 43110237 1
31 Electric Box Cover 01413008 01413008 1
32 Centifugal Fan 10312401 10312401 2
33 Capacitor 33010020 33010020 1
34 Motor 15707302 15707302 1
35 Motor Clamp 70819522 70819522 4
36 Front propeller housing 22202031 22202031 2
37 Rear propeller housing 22202032 22202032 2
38 Rear Side Plate Sub-assy 0130201501 0130201501 1
39 Motor Support Sub-assy 01709532 01709532 1
40 Filter Sub-assy 11122013 11122013 1
41 Panel Grille 22412010 22412010 2
42 Panel Grille Buckle 2 26252003 26252003 4
43 Remote Control 305125033 305125033 1
44 Cooling coil assy 01109532 01109532 1
45 Panel Grille Buckle 1 26252002 26252002 4
46 Environment Sensor 39000186 39000186 1
47 Sensor Insert B 42020063 42020063 1
48 Cover Plate of Evaporator 01072409 01072409 1
49 Left Decorative Board 26112028 26112028 1
50 Left Mounting Plate 01332405 01332405 1
51 Foam Sub-assy of Left Side Plate 12312403 12312403 1
Above data is subject to change without notice,please refer the SP in global service website.
