Clean and maintenance
15
Caution: Do not wash or wipe
the aluminium shaft of blade
and the black sponge.
Press point
Press point
Caution: There is lubricating oil at
the shaft rubber block. Do not clean
or wipe it.
③Remove 4 black screws at both sides used for fixing the bottom case.
④Press the appointed positions at both sides with both thumbs (as shown in
below figure), hold the bottom case with other four fingers and then lift it
upwards, and then remove the bottom case of the air conditioner.
Caution
When user has remove the bottom case, do not touch the evaporator to prevent
scratching the fingers.
⑤Immerse the cloth into water (below 45℃), wring it out and then wipe the
dirty position of the unit. After that, dry the cloth.
