Gree GAC09AA-A3RNB4C - Major Component Removal (Evaporator, Condenser, Compressor)

Service Manual
Installation and Maintenance
54
reversion loop
ProcedureStep
axial ow blade
washer
nut
motor
10.Remove reversion loop sub-assy
11.Remove axial ow blade sub-assy
12.Remove outdoor motor
screw
Twist off the screws used for xing the
reversion loop with screwdriver, pull it
upward and then remove the reversion
loop sub-assy.
Twist off the nuts used for xing the axial
ow blade, take out the washer and then
remove the axial ow blade.
Twist off the screws used for xing the
motor and then remove the motor.
screw
