29
Service Manual
Installation and Maintenance
Above data is subject to change without notice.
No.
Description
Part Code
QtyGDN16AH-K4EBB1C GDN20AH-K4EBB1C
Product code CK051026300 CK051026400
1 Water Tank Assy 20186542 20186542 1
2 Water Tank Cover 22246087 22246087 1
3 Float meter sub-assy 26116528 26116528 1
4 Shield Assy (Electric) 00004200016 00004200016 1
5 Front Panel 20006091S 20006091S 1
6 Cover of Waterspout 22246079 22246079 1
7 Front Case 22206521 22206521 1
8 Membrane 63066044 63066044 1
9 Display Board 30561066 30561066 1
10 LCD Cover 20126114 20126114 1
11 Diversion Circle 10376042 10376042 1
12 Temperature Sensor 390000592 390000592 1
13 Detecting Plate 30070018 30070018 1
14 Support(Sensor) 24216025 24216025 1
15 Centrifugal Fan 10316055 10316055 1
16 Fan Motor 1501621406 1501621406 1
17 Wire Clamp 26116069 26116069 1
18 Motor Support 24216094 24216094 1
19 Cover Plate 20126179 20126179 1
20 Handle 26236023 26236023 1
21 Capillary Sub-assy 03000600263 03000600264 1
22 Condenser Sub-Assy 01136038 01136039 1
23 Evaporator Sub-Assy 01036037 01036047 1
24 Filter Sub-Assy 11126522 11126522 1
25 Filter 11126512 11126512 1
26 Rear Case Sub-assy 00013500003 00013500003 1
27 Power Cord 4002028601 4002028601 1
28 Electric Box Cover 01256025 01256025 1
29 Electric Box Assy 10000201338 10000201338 1
30 Main Board 30131454 30131454 1
31 Capacitor CBB61 3301074716 3301074716 1
32 Capacitor 3300002242 3300002242 1
33 Liquid Level Switch Sub-assy 45016014 45016014 1
34 Water Tray 20186159 20186159 1
35 Rubber Plug(Water Tray) 76716507 76716507 1
36 Drainage Joint Sub-assy 06126012 06126012 1
37 Covering Plate 01225600004A 01225600004A 1
38 Inhalation Tube Sub-assy 03001000146 03001000146 1
39 Compressor and Fittings 00106538 00106097 1
40 Compressor Gasket 76716097 76716097 3
41 Discharge Tube Sub-assy 03636611 03636611 1
42 Support Sub-assy 01706029P 01706029P 1
43 Chassis 22226066 22226066 1
44 Castor 24236053 24236053 4
