Gree GEH18AA-K3DNA1D

64
Installation and Maintenance
Service Manual
NO.
Description
Part Code
QtyGEH12AA-K3DNA1D/I GEH18AA-K3DNA1D/I
Product Code CV010N02600 CV010N02400
1 Front Panel Assy 20012756 20012756 1
2 Filter Sub-Assy 11122139 11122139 1
3 Front Case Assy 20012601 20012601 1
4 Evaporator Assy 01100100160 01100100164 1
5 Cold Plasma Generator 1114001604 1114001604 1
6 Rear Case Assy 000001000051 22202462 1
7 Centrifugal Fan 10312005 10312005 1
8 Fan Motor 1570410001201 15704100012 1
9 SteppingMotor 1521210101 1521210101 1
10 Crank 73012005 73012005 1
11 Swing Assy 10102042 10102042 1
12 Terminal Board 42011233 42011233 1
13 Switch Board 30112007 30112007 1
14 Display Board 30568131 30568131 1
15 Fuse 46010030 46010030 1
16 Radiator / / /
17 Signal Wire 4003004202 4003004202 1
18 Jumper 4202300112 4202300114 1
19 Main Board 300002000631 300002000631 1
20 Electric Box 20112116 20112116 1
21 Electric Box Assy 100002002951 100002002386 1
22 Air Louver (upper) 10512143 10512143 2
23 Swing Lever 10582096 10582096 1
24 Shaft of Guide Louver 10542020 10542020 1
25 Water Tray Assy 20182141 20182141 1
26 Air Louver (lower) 10512144 10512144 1
27 Axis (lower step motor) 10542034 10542034 1
28 SteppingMotor 1521210805 1521210101 1
29 Connecting Cable 4002052317 4002052317 0
30 Temperature Sensor 3900004508 3900004508 1
31 Remote Controller 305001000111 305001000111 1
32 Temperature Sensor 390000591 390000591 1
Above data is subject to change without notice.
