Gree GEH18AA-K3DNA1D

2
Technical Information
Service Manual
Parameter Unit Value
Model GEH12AA-K3DNA1D GEH18AA-K3DNA1D
Product Code CV010002600 CV010002400
Power
Supply
Rated Voltage V
～
220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity(Min~Max) W 3500 5200
Heating Capacity(Min~Max) W 3750 5330
Cooling Power Input(Min~Max) W 1100 1600
Heating Power Input(Min~Max) W 1000 1500
Cooling Current Input A 4.85 7.10
Heating Current Input A 4.33 6.65
Rated Input W 1600 2500
Rated Current A 5.9 10.9
Air Flow Volume(SH/H/HM/M/LM/L/SL) m
3
/h 600/520/480/440/400/360/280 700/650/580/520/460/410/320
Dehumidifying Volume L/h 1.2 1.8
EER W/W 3.18 3.25
COP W/W 3.75 3.55
SEER W/W 6.4 6.5
HSPF W/W / /
Application Area m
2
16-24 23-34
Indoor
Unit
Indoor Unit Model GEH12AA-K3DNA1D/I GEH18AA-K3DNA1D/I
Indoor Unit Product Code CV010N02600 CV010N02400
Fan Type Centrifugal Centrifugal
Fan Diameter Length(DXL) mm Φ370X80 Φ370X80
Cooling Speed
(SH/H/HM/M/LM/L/SL)
r/min
750/650/600/550/500/450/350
720/620/570/520/470/420/320
840/800/720/650/580/530/410
810/770/690/620/550/500/380
Heating Speed
(SH/H/HM/M/LM/L/SL)
r/min
750/650/600/550/500/450/350
720/620/570/520/470/420/320
930/840/760/690/620/570/480
850/800/720/650/580/530/470
Fan Motor Power Output W 30 30
Fan Motor RLA A 0.15 0.15
Fan Motor Capacitor μF / /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Φ7 Φ7
Evaporator Row-n Gap mm 2-1.3 2-1.3
Evaporator Coil Length (LXDXW) mm 511X400X25.4 511X400X25.4
Swing Motor Model MP24EB/MP24AE MP24EB/MP24AE
Swing Motor Power Output W 1.5/1.5 1.5/1.5
Fuse Current A 3.15 3.15
Sound Pressure Level
(SS/H/MH/M/ML/L/SL)
dB (A) 42/40/38/36/34/31/25 47/45/42/40/37/35/31
Sound Power Level
(SS/H/MH/M/ML/L/SL)
dB (A) 52/50/48/46/44/41/35 57/55/52/50/47/45/41
Dimension (WXHXD) mm 700X215X600 700X215X600
Dimension of Carton Box (LXWXH) mm 785X280X682 785X280X682
Dimension of Package(LXWXH) mm 788X283X697 788X283X697
Net Weight kg 15.5 15.5
Gross Weight kg 18.5 18.5
2. Specications
2.1 Specication Sheet
