Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
Qty
GEH12AA-K3DNA1D/O
Product Code CV010W02600
1 Electric Box Assy 100002002950 1
2 Electric Box Sub-Assy 017007000476 1
3 Main Board 300027000469 1
4 Reactor 43130184 1
5 Terminal Board 42010313 1
6 Wire Clamp 71010103 1
7 Front Grill 22413049 1
8 Front Panel 01533034P 1
9 Axial Flow Fan 10333004 1
10 Chassis Sub-assy 017000000126P 1
11 Fan Motor 1501308506 1
12 Top Cover Plate 01253073 1
13 Motor Support 0170310403 1
14 Condenser Assy 01100200173 1
15 Rear Grill 01473009 1
16 Electronic Expansion Valve 07133978 1
17 Cut off Valve 07133474 1
18 Big Handle 262334332 1
19 Valve 07100003 1
20 Valve Support 0171314201P 1
21 Right Side Plate Sub-Assy 0130317801 1
22 4-Way Valve Assy 030152000339 1
23 Clapboard Sub-Assy 0123338502 1
24 Magnet Coil 4300040050 1
25 Compressor and Fittings 009001000181 1
26 Drainage Connecter 06123401 1
27 Electrical Heater(Compressor) / /
28 Electrical Heater(Chassis) 7651000414 1
