GREE DC Inverter Multi VRF System II Service Manual
152
Parts list
NO.
Name of Part
GMV-141WL/C-T
Product Code
CN850W0880
Part Code
Quantity
1
Chassis Assy
209058060095
1
2
Electrical Heater
765100049
1
3
Condenser Assy
100060114
1
4
Silencer
7245012
1
5
Strainer
721212101
1
6
Temp Sensor Sleeving
5212423
1
7
Sensor Insert
42020063
1
8
Motor Support Sub-Assy
17012060039
1
9
Brushless DC Motor
150104060013
1
10
Axial Flow Fan
1043410000801
1
11
Left Side Plate
012055000007P
1
12
Left Side Plate
12055000007
1
13
Cabinet
012022000003P
1
14
Cabinet
12022000003
1
15
Diversion Circle
10474100003
1
16
Front Grill
1572800003
1
17
Gas-liquid Separator
7424145
1
18
Compressor and Fittings
9001060150
1
19
Nut with Washer
70310014
3
20
Electrical Heater(Compressor)
7651521238
1
21
4-Way Valve Assy
30152060195
1
22
4-way Valve
4300008201
1
23
Filter
7224803
1
24
Cut off Valve
7334100016
1
25
Temp Sensor Sleeving
5212423
3
26
Magnet Coil (electromagnetic valve)
4304410018903
1
27
Sensor Insert
42020063
3
28
Strainer
721650101
1
29
Electromagnetic Valve
43000054
1
30
Magnet Coil (electromagnetic valve)
4304410018902
1
31
Electronic Expansion Valve
43044100173
1
32
Electric Expand Valve Fitting
4304413252
1
33
Pressure Protect Switch
46020006
1
34
Oil Separator
7424105
1
35
Temp Sensor Sleeving
5212423
1
36
Sensor Insert
42020063
1
