GREE DC Inverter Multi VRF System II Service Manual
164
NO.
Name of Part
GMV-H224WL/A-X,GMV-224WL/C-X
Product Code
CN850W0330
CN850W0510
Part Code
Quantity
17
Diversion Circle
10474100003
2
18
Cabinet Assy
01514100015
1
19
Handle
26235253
1
20
Front Side Plate
01314100082P
1
21
Nozzle for Adding Freon
06120012
1
22
Gas-liquid Separator
07424140
1
23
Pressure Protect Switch
4602000902
1
24
Cut off Valve
07334100011
1
25
Compressor and Fittings
00204100013
1
26
Electrical Heater(Compressor)
765152128
1
27
Oil Separator Sub-Assy
07424100045
1
28
Oil Separator
07424105
1
29
One way Valve
07130118
1
30
Strainer
07415200002
1
31
Capillary Sub-assy
04004100020
1
32
Electromagnetic Valve
43000054
1
33
Magnet Coil
4304000417
1
34
Electric Expansion Valve Sub-Assy
43044100160
1
35
One Way Valve
07133618
1
36
Electronic Expansion Valve
43044100173
1
37
Electric Expand Valve Fitting
4304413219
1
38
Sensor (High Pressure)
322101032
1
39
Sensing Device
322101002
1
40
Drainage Joint
26113009
1
41
Plate-type Heat Exchanger Assy
00904100025
1
42
Strainer
07212001
1
43
Electronic Expansion Valve
3044100172
1
44
Electric Expand Valve Fitting
4304413220
1
45
4-Way Valve Sub-Assy
04044100059
1
46
Gas By-pass sub- assy
04534100101
1
47
Magnet Coil
4304000416
1
48
Strainer
07212403
1
49
Condenser Assy
01124100138
1
50
Rear Grill
01574100011
1
51
Discharge Charge Valve
07133771
1
52
Discharge Charge Valve Sub-Assy
07334100062
1
53
4-Way Valve
43044100164
1
54
Magnet Coil
4300040032
1
55
Cut off Valve
07130239
1
56
Cut off Valve
07334100054
1
Above data is subject to change without notice, pls reference the SP in global service website.
