GREE DC Inverter Multi VRF System II Service Manual
168
NO.
Name of Part
GMV-H335WL/A-X,GMV-335WL/C-X
Product Code
CN850W0350
CN850W0500
Part Code
Quantity
19
Front Side Plate
01314100091P
1
20
Sensor Sub-assy
39008000121G
1
21
Chassis Sub-assy
01194100081P
1
22
Oil Separator
07424100050
1
23
Low Pressure Survey Valve Sub-assy
07334100065
1
24
Strainer
07414100024
1
25
Cut off Valve
07130208
1
26
Compressor and Fittings
00204100015
1
27
Electric Heater(Compressor)
7651540714
1
28
Cut off Valve
07334100014
1
29
Connecting Pipe Sub-assy(Big Vavle)
05024100925
1
30
Nozzle for Adding Freon
06120012
1
31
Pressure Protect Switch
4602000902
1
32
Connection Pipe Sub-assy
05024100948
1
33
Cut off Valve
07334100013
1
34
Strainer
07210032
1
35
Capillary Sub-assy
04004100022
1
36
Electromagnetic Valve
43003091
1
37
Magnet Coil
4304000413
1
38
Rear Side Plate
01314100092P
1
39
Handle
26235253
2
40
Sensor (High Pressure)
322101032
1
41
Sensing Device
322101002
1
42
Plate-type Heat Exchanger
00904100004
1
43
Electronic Expansion Valve
43044100172
1
44
Electric Expand Valve Fitting
4304413204
1
45
Plate-type Heat Exchanger Assy
00904100029
1
46
4-Way Valve Assy
04044100061
1
47
Strainer
07414100024
1
48
4-way Valve
43000339
1
49
One way Valve
07335210
1
50
Magnet Coil
4300040032
1
51
Discharge Charge Valve Sub-Assy
07334100066
1
52
Discharge Charge Valve
07133771
1
53
Condenser Assy
01124100151
1
54
Filter
0341010701
1
55
One way Valve
04324001
1
56
Electronic Expansion Valve
43044100190
1
57
Electric Expand Valve Fitting
4304413205
1
58
Rear Grill
01574100014
2
59
Electric Expansion Valve Sub-Assy
43044100211
1
60
Magnet Coil
4304000416
1
61
Electromagnetic Valve
43000054
1
62
Gas By-pass sub- assy
04534100108
1
Above data is subject to change without notice, pls reference the SP in global service website.
