GMV5 DC INVERTER VRF UNITS SERVICE MANUAL
197
Step 9: Install a new oil balancer.
The original oil balancer, if is found to have no impurities or other objects, can be used further more. This
part serves as a container and it does not have complex structure. However, if it contains impurities or
other objects, replace it. This is because a dirty oil balancer cannot be thoroughly cleaned.
Step 10: Install a new oil separator.
If the original oil separator contains impurities inside, replace it.
1. Put the
gas/liquid
separator on a
proper position
2. Connect the
inlet pipe of the
separator with
the outlet pipe
3. Weld the
pipes together
4. Screw the
separator onto the
chassis
1. Put the oil
balancer on
a proper
position
2. Weld the
connecting pipes
of the oil balancer
3. Screw the
oil balancer
4. Weld the oil
balancer
components
To Next Page
