Gree GMV-400WM/G-X

Gree GMV6 DC Inverter VRF Units Service Manual
280
No. Name Material code
Vulnerable part
*
Qty
19 Covering plate 012035000246P 1
20
Left panel
012062000017P
1
21
Right panel
012167000014P
1
22
Left panel
012062000016P
1
23
Electronic expansion valve
072009060012
*
1
24
Cut-off valve
07334100053
*
1
25
Fluoride injection mouth
06130002
*
1
26
Cut-off valve
07334100014
*
1
27
Filter
07415200002
*
1
28 Solenoid valve 43000072 * 1
29
Compressor and its accessories
009001060198
*
1
30
Pressure switch
4602000911
*
1
31
Chassis assembly
017000060119P
1
32
Right side plate assembly
017038060026P
1
33
Gas-liquid separator
035027060004
*
1
34
Filter
07218603
*
1
35
Oil separator
035028060002
*
1
36
4-way valve
43000339
*
1
37 One-way valve 71001060007 * 1
38
Fluoride injection mouth
061200101
*
1
39
Fluoride injection mouth
06120012
*
1
40
Condenser assembly
011002060249
*
1
41
Filter
0341010701
*
1
42
Mesh enclosure
016001060012
*
1
43
Covering plate
012035000247P
1
44
Terminal board
422000060055
*
1
45
Communication interface board
300014060038
*
1
46 Terminal board 422000060004 * 1
47
Filter board
300020060004
*
1
48
Main board
300027000582
*
2
49
Radiator
4901800008801
*
1
50
Main board
300027060023
*
1
51
Reactor
450004060005
*
1
52
Main board
300027000591
*
1
53
Electric appliance box assembly
100002064633
*
1
54
Electric heating belt (compressor)
7651540714
*
1
55 4-way valve coil 072010060002 * 1
56
Electronic expansion valve coil
4304413274
*
1
57
Electronic expansion valve coil
4304413264
*
1
58
Solenoid valve coil
072001060009
*
1
59
Solenoid valve coil
072001060008
*
1
60
Solenoid valve coil
072001060007
*
1
61
Solenoid valve coil
072001060006
*
1
62
Temperature sensor assembly
390002060037
*
1
63
Pressure sensor
32210103
*
1
64 Pressure sensor 32218000008 * 1
Above data is subject to change without notice,pls reference the SP in global service website.
