Gree GMV-400WM/G-X

Gree GMV6 DC Inverter VRF Units Service Manual
6
Model - GMV-1175WM/G-X GMV-1230WM/G-X GMV-1295WM/G-X GMV-1360WM/G-X
Heating power input kW 13.1+16.9 16.9+16.9 16.9+20.1 20.1+20.1
Cooling current
input
A 24.7+29.0 29.0+29.0 29.0+36.6 36.6+36.6
Heating current
input
A 23.4+30.2 30.2+30.2 30.2+35.9 35.9+35.9
Rated power input kW 26.85+27.41 27.41+27.41 27.41+27.41 27.41+27.41
Rated current A 48+49 49+49 49+49 49+49
Cooling operation
range
°C -5~52 -5~52 -5~52 -5~52
Heating operation
range
°C -30~24 -30~24 -30~24 -30~24
Refrigerant type - R410A R410A R410A R410A
Refrigerant charge kg 8+8.3 8.3+8.3 8.3+8.3 8.3+8.3
Maximum drive IDU
NO.
unit 64 64 64 64
Gas pipe mm Φ38.1 Φ38.1 Φ38.1 Φ41.3
Liquid pipe mm Φ19.05 Φ19.05 Φ19.05 Φ19.05
Outline dimensions
(W × D × H)
mm
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690
Packing dimensions
(W × D × H)
mm
1400×830×1855+
1400×830×1855
1400×830×1855+
1400×830×1855
1400×830×1855+
1400×830×1855
1400×830×1855+
1400×830×1855
Net weight kg 350+350 350+350 350+355 355+355
Gross weight kg 365+365 365+365 365+370 370+370
Model - GMV-1399WM/G-X GMV-1455WM/G-X GMV-1510WM/G-X GMV-1565WM/G-X
HP HP 50 52 54 56
Combination mode
- 12+18+20 10+20+22 10+22+22 12+22+22
-
GMV-335WM/G-X+
GMV-504WM/G-X+
GMV-560WM/G-X
GMV-280WM/G-X+
GMV-560WM/G-X+
GMV-615WM/G-X
GMV-280WM/G-X+
GMV-615WM/G-X+
GMV-615WM/G-X
GMV-335WM/G-X+
GMV-615WM/G-X+
GMV-615WM/G-X
Cooling capacity kW 139.9 145.5 151.0 156.5
Heating capacity kW 157.0 163.5 169.5 175.5
Outdoor static
pressure
Pa 0/110 0/110 0/110 0/110
Noise (sound
pressure level)
dB(A) 66 66 67 67
Power -
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
Cooling power input kW 7.7+12.3+13.8 6.2+13.8+16.2 6.2+16.2+16.2 7.7+16.2+16.2
Heating power input kW 7.8+12.9+13.1 5.9+13.1+16.9 5.9+16.9+16.9 7.8+16.9+16.9
Cooling current
input
A 13.8+22.0+24.7 11.1+24.7+29.0 11.1+29.0+29.0 13.8+29.0+29.0
Heating current
input
A 13.9+23.1+23.4 10.5+23.4+30.2 10.5+30.2+30.2 13.9+30.2+30.2
Rated power input kW 13.50+26.30+26.85 13.15+26.85+27.41 13.15+27.41+27.41 13.50+27.41+27.41
Rated current A 24.1+47+48 23.5+48+49 23.5+49+49 24.1+49+49
Cooling operation
range
°C -5~52 -5~52 -5~52 -5~52
Heating operation
range
°C -30~24 -30~24 -30~24 -30~24
Refrigerant type - R410A R410A R410A R410A
Refrigerant charge kg 5.7+8+8 5.5+8+8.3 5.5+8.3+8.3 5.7+8.3+8.3
Maximum drive IDU
NO.
unit 66 69 71 74
Gas pipe mm Φ41.3 Φ41.3 Φ41.3 Φ41.3
Liquid pipe mm Φ19.05 Φ19.05 Φ19.05 Φ19.05
Outline dimensions
(W × D × H)
mm
930×775×1690+
1340×775×1690+
1340×775×1690
930×775×1690+
1340×775×1690+
1340×775×1690
930×775×1690+
1340×775×1690+
1340×775×1690
930×775×1690+
1340×775×1690+
1340×775×1690
Packing dimensions
(W × D × H)
mm
1000×830×1855+
1400×830×1855+
1400×830×1855
1000×830×1855+
1400×830×1855+
1400×830×1855
1000×830×1855+
1400×830×1855+
1400×830×1855
1000×830×1855+
1400×830×1855+
1400×830×1855
Net weight kg 220+295+350 215+350+350 215+350+350 220+350+350
