GMV5 DC INVERTER VRF UNITS SERVICE MANUAL
178
Compressor
Current (A)
Evaporating
Temp. (°C)
Condensing
Temp. (°C)
Note: You can infer from the preceding figures the current of the compressors operating at other
frequency bands.
②For inverter compressor E405DHD-38D2YG:
The figure below shows current curves that change with evaporating temperature and condensing
temperature while the compressor works at 30 Hz.
The figure below shows current curves that change with evaporating temperature and condensing
temperature while the compressor works at 60 Hz.
Current curve
Condensing temp.
Evaporating temp. (°C)
Secondary current (A)
The figure below shows current curves that change with evaporating temperature and condensing
temperature while the compressor works at 90 Hz.
