Gree GMV6 DC Inverter VRF Units Service Manual
Model - GMV-504WM/G-X GMV-560WM/G-X GMV-615WM/G-X GMV-680WM/G-X
Cooling current input A 22.0 24.7 29.0 36.6
Heating current input A 23.1 23.4 30.2 35.9
Rated power input kW 26.30 26.85 27.41 27.41
Rated current A 47 48 49 49
Compressor type - Inverter scroll Inverter scroll Inverter scroll Inverter scroll
Compressor function - EVI EVI EVI EVI
Compressor quantity N 1 2 2 2
Refrigeration oil No.
of compressor
- FV68H FV68H FV68H FV68H
Refrige
ration
oil
charge
Gross L 6.1 7.2 7.2 7.2
L 1.1 1.1×2 1.1×2 1.1×2
The others L 5 5 5 5
°C -5~52 -5~52 -5~52 -5~52
°C -30~24 -30~24 -30~24 -30~24
Refrigerant type - R410A R410A R410A R410A
Refrigerant charge kg 8 8 8.3 8.3
unit 29 33 36 39
Gas pipe mm Φ28.6 Φ28.6 Φ28.6 Φ28.6
Liquid pipe mm Φ15.9 Φ15.9 Φ15.9 Φ15.9
Outline dimensions
(W × D × H)
mm 1340×775×1690 1340×775×1690 1340×775×1690 1340×775×1690
Packing dimensions
(W × D × H)
mm 1400×830×1855 1400×830×1855 1400×830×1855 1400×830×1855
Net weight kg 295 350 350 355
Gross weight kg 310 365 365 370
2.2 Parameters of Combined Modules
Model - GMV-735WM/G-X GMV-785WM/G-X GMV-839WM/G-X GMV-895WM/G-X
HP HP 26 28 30 32
Combination mode
- 12+14 12+16 12+18 10+22
-
GMV-335WM/G-X+
GMV-400WM/G-X
GMV-335WM/G-X+
GMV-450WM/G-X
GMV-335WM/G-X+
GMV-504WM/G-X
GMV-280WM/G-X+
GMV-615WM/G-X
Cooling capacity kW 73.5 78.5 83.9 89.5
Heating capacity kW 82.5 87.5 94.0 100.5
Pa 0/110 0/110 0/110 0/110
Noise (sound
pressure level)
dB(A) 62 63 64 64
Power -
Cooling power input kW 7.7+9.2 7.7+10.8 7.7+12.3 6.2 +16.2
Heating power input kW 7.8+9.5 7.8+10.7 7.8+12.9 5.9+16.9
A 13.8+16.4 13.8+19.3 13.8+22.0 11.1+29.0
A 13.9+17.0 13.9+19.1 13.9+23.1 10.5+30.2
Rated power input kW 13.50+18.18 13.50+18.74 13.50+26.30 13.15+27.41
Rated current A 24.1+32.5 24.1+33.5 24.1+47 23.5+49
°C -5~52 -5~52 -5~52 -5~52
°C -30~24 -30~24 -30~24 -30~24
Refrigerant type - R410A R410A R410A R410A
Refrigerant charge kg 5.7+7 5.7+7.5 5.7+8 5.5+8.3
unit 43 46 50 53
