Gree GMV-80WL/C-T User Manual

GREE DC Inverter Multi VRF System II Service Manual
6
Model
GMV-H224
WL/A-X
GMV-H280
WL/A-X
GMV-H335
WL/A-X
GMV-224W
L/C-X
GMV-280W
L/C-X
GMV-335W
L/C-X
ion pipe
Liquid
mm
Ф9.52 Ф9.52 Ф9.52 Ф12.7 Ф9.52 Ф12.7
Connection
Method
Brazing
Connection
Brazing
Connection
Brazing
Connection
Brazing
Connection
Brazing
Connection
Brazing
Connection
Net weight
kg
133 166 133 166 177 177
Model
GMV-80WL/A
-T
GMV-100WL/A
-T
GMV-121WL/A
-T
GMV-80WL/C
-T
Cooling capacity
kW
8 10 12.1 8
Heating capacity
kW
9 11 13.0 9
Circulating air volume
m
3
/h
3900 4000 4400 3900
Noise
(Sound Power Lever)
dB(A)
67 67 68 68
Refrigerant charge
volume
kg
1.8 1.8 2.0 1.8
Energy efficiency
level
Level
1 1 1 1
Power supply
220240V 50Hz
208
230V 60Hz
220240V 50Hz
208
230V 60Hz
220240V 50Hz
208
230V 60Hz
220240V 50Hz
208
230V 60Hz
Rated
power
input
Cooling
kW
2.00 2.70 3.20 2.05
Heating
kW
1.90 2.40 3.00 1.90
Unit Dimensions
(mm)(WxDxH)
980×360×790
Package Dimensions
(mm)(WxDxH)
1097x477x937
Compressor QXAS-D32zX090A
Water-proof level IPX4 IPX4 IPX4 IPX4
Suitable climite T1 T1 T1 T1
Connection
pipe
Gas
mm
Φ15.9 Φ15.9 Φ15.9 Φ15.9
Liquid
mm
Φ9.52 Φ9.52 Φ9.52 Φ9.52
Connection
Method
Flare Flare Flare Flare
Net weight
kg
80 80 85 80
Model
GMV-100WL/C-T GMV-121WL/C-T GMV-141WL/C-T
Cooling capacity
kW
10 12.1 14.1
Heating capacity
kW
11 13.0 16.0
Circulating air volume
m
3
/h
4000 4400 5200
Noise
(Sound Power Lever)
dB(A)
69 70 70
Refrigerant charge
volume
kg
1.8 2.0 3.3
Energy efficiency
level
Level
1 1 1
Power supply
220240V 50Hz
208230V 60Hz
220240V 50Hz
208230V 60Hz
220240V 50Hz
208230V 60Hz
Rated
power
input
Cooling
kW
3.45 3.45 3.92
Heating
kW
2.70 2.70 4.16
Unit Dimensions
(mm)(WxDxH)
980×360×790 940×460×820
Package Dimensions
(mm)(WxDxH)
1097x477x937 1023 x563 x973

Gree GMV-80WL/C-T Specifications

General

Brand	Gree
Model	GMV-80WL/C-T
Category	Air Conditioner
Language	English
