GREE DC Inverter Multi VRF System II Service Manual
118
Removal operation for panel
Remark: Before removing the panel, please make sure that the unit is disconected with the power
Process
Operation Instruction
4. Remove left
side plate and
rear side plate
●
Loose screws fixing left side
plate and rear side plate with
screwdriver
● remove the rear side plate
Removal operation for blade
Remark: Before removing the motor, please make sure that the unit is disconnected with the power.
Process
Operation Instruction
1. Remove grille
● Loose screws fixing the panel
with screwdriver
● Then remove the grille
2. Remove
blade
● Loosen nuts fixing the blade
with wrench
● Then remove the blade and put
it on the floor flatly
